PXIe Microwave Vector Signal Source test set

M9383A

PXIe Microwave Vector Signal Source test set

Industry’s most upgradeable performance signal generator

Collection:

PXI Products###PXI Signal Generators

Customizable, High-Performance PXIe Signal Generator

Based on the PXIe industry standard, the Keysight M9383A PXIe microwave signal generator is flexible enough to solve your immediate test needs, and upgradable for what comes next – whether that’s testing at higher frequencies or shifting to high volume production.

Modular test solution for design validation that can be efficiently leveraged into manufacturing
Flexible design offers rapid and easy upgrades

Supports a variety of uses from LO and blocking applications to 5G test
Keysight PathWave Signal Generation software simplifies the creation of 5G NR waveforms

Keysight Technologies

ATP/Direct

5992-1928EN

Customizable, High-Performance PXIe Signal Generator

Modular test solution for design validation that can be efficiently leveraged into manufacturing
Flexible design offers rapid and easy upgrades

Supports a variety of uses from LO and blocking applications to 5G test
Keysight PathWave Signal Generation software simplifies the creation of 5G NR waveforms

Bandwidth options: ; Baseband Generator Mode: Waveform Playback; Form factor: ; Frequency: 44 GHz; Frequency Options: ; Frequency switching speed: 250 µs; Harmonics @ 1 GHz: -46 dBc; Maximum bandwidth: 1 GHz; Maximum frequency: 44 GHz; Maximum modulation bandwidth: 1 GHz; Maximum output power: 19 dBm; Non-Harmonics @1 GHz: -45 dBc; Number of outputs: 1; Output power @1 GHz: 19 dBm; Performance Level: ◆◆◆◆◇◇; Phase noise @1 GHz (10 kHz offset): -118 dBc/Hz; Phase noise @1 GHz (20 kHz offset): -118 dBc/Hz; Platform: ; Sweep Mode: ; Type: ; Waveform Playback Memory: 1024 MSa
