Configurable Multiport Test Set

Maximize your testing capabilities to extend the number of ports on your vector network analyzer

Frequency range 50 MHz to 20 GHz.
Up to 10-port full crossbar measurement or maximum 22-port measurement capability.
Supported by the 4-port Vector Network Analyzer (VNA) including E5080B ENA
Extremely fast switching speed optimized for the VNA
Temperature control function for superior measurement stability
Internal DC sources for controlling an active multiport DUT

The E5092A configurable multiport test set, combined with the 4-port VNA (E5070B/E5071B/E5071C/E5080A/E5080B), offers a complete multiport solution up to 20 GHz for a wide range of R&D and manufacturing measurement applications. This powerful combination is suited for testing multiport devices such as front-end modules (FEM) for cellular handsets, WLAN application or other general-purpose multiport devices. The test set offers flexible configuration capability that enables customization of switch matrix depending on required applications.

View: Application Note – Comprehensive Multiport Solution for the ENA Network Analyzer

Keysight Technologies

ATP/Direct

5992-0291EN

Frequency range 50 MHz to 20 GHz.
Up to 10-port full crossbar measurement or maximum 22-port measurement capability.
Supported by the 4-port Vector Network Analyzer (VNA) including E5080B ENA
Extremely fast switching speed optimized for the VNA
Temperature control function for superior measurement stability
Internal DC sources for controlling an active multiport DUT

View: Application Note – Comprehensive Multiport Solution for the ENA Network Analyzer

Connector size: ; Connector type: ; Frequency range: ; Maximum frequency: 20 GHz; Number of Internal Sources: ; Number of built-in ports: ; Ports: 22; Switch type: ; Type: ; VNA Series: ; VNA Type: Benchtop
